Contactor
Kontaktor PowerSys Control 3P (25A) 220VAC
Kode Produk:
C25-220VAC
Spesifikasi Teknis
Fase :
3 P
Beban Resistif (AC-3) :
25 A
Beban Induktif (AC-1) :
32 A
Komposisi Kontak Bantu :
1N/O + 1N/C
Tegangan Sirkuit Kontrol :
220 VAC
Range of product :
C Series
Product or component type :
Power Contactor
Utilisation category :
AC-3, AC-4
[Ue] rated operational voltage :
Power circuit: <= 690 V AC 50/60 Hz
[Ie] rated operational current :
25 A (Ac-3) at Ue = 380/400 V, 50/60 Hz (power circuit)
Motor power (kW) :
4 kW at 380/400 V AC (AC-3), 50/60 Hz
Motor power (hp) :
5.5 hp at 380/400 V AC (AC-3), 50/60 Hz
Pole contact composition :
3 NO main contacts
[Ith] conventional free air thermal current :
25 A
Rated breaking capacity :
According to utilisation category AC-3 / AC-4 (IEC 60947- 4-1)
[Ui] rated insulation voltage :
Power circuit: 690 V conforming to IEC 60947-4-1
[Uimp] rated impulse withstand voltage :
6 kV conforming to IEC 60947
Mechanical durability :
10,000,000 Mcycles operations
Electrical durability :
1,000,000 Mcycles operations (AC-3)
Control circuit type :
AC
Coil technology :
AC electromagnetic coil
Control circuit voltage limits :
Pick-up: 85% – 110% Us Drop-out: 20% – 75% Us
Inrush power in VA :
3600 VA
Hold-in power consumption in VA :
360 VA
Komposisi Kontak Bantu :
1 NO + 1 NC auxiliary contacts (standard)
Auxiliary contacts type :
Instantaneous
Mounting support :
Screw mounting 35 mm DIN rail
Standards :
IEC / EN 60947-4-1 | GB/T 14048.4
IP degree protection :
IP20 front face conforming to IEC 60529
Tinggi :
8,3 cm
Lebar :
5,65 cm
Kedalaman :
9,7 cm
Net weight :
490,6 g
Warranty (in months) :
12
